You are welcomed to come to our factory to buy the latest selling, low price, and high-quality N5182B MXG Signal Generators. N5182B MXG X-Series RF vector high performance signal generators are fine-tuned to be your “golden transmitter” in R&D with 9 kHz to 6 GHz frequency coverage. Simulate real-world signals with real-time capabilities with Signal Studio software.
9 kHz - 3 GHz MXG Vector High-Performance Signal Generator
You are welcomed to come to our factory to buy the latest selling, low price, and high-quality N5182B MXG Signal Generators. The Keysight N5182B analog and vector MXG and EXG signal generators deliver unmatched performance in five key categories: phase noise and spectral purity, bandwidth, EVM, ACPR, and output power.
Perform advanced receiver testing compatible with the latest standards using the MXG or EXG and Signal Studio software: define signal parameters, transfer them to the instrument, and use closed-loop or interactive control during signal generation.
Take your designs to their limit with outstanding hardware performance, including unmatched phase noise and spurious characteristics.
Drive power amplifiers and characterize nonlinear behavior with industry-leading adjacent channel power ratio (ACPR) and output power.
Test wideband devices with factory-equalized 160 MHz RF bandwidth.
Reduce the time spent on signal creation with PathWave Signal Generation software, including LTE, WLAN, and GNSS.
Lower your cost of ownership with 3-year cal cycles and comprehensive solutions for self-maintenance.
Frequency ranges: 9 kHz to 6 GHz
Phase noise at 1 GHz, 20 kHz offset: –146 dBc/Hz
Spurious at 1 GHz (nonharmonics) : –96 dBc
Output power at 1 GHz: +27 dBm
ACPR (vector) W-CDMA 64 DPCH: –73 dBc
EVM (vector) 802.11ac/LTE: 0.4 percent
Bandwidth (vector): 160 MHz
Arbitrary waveform memory (vector): 1024 MSa
standard phase noise
standard output power, +18 dBm
CW signal generation
vector (I/Q) modulator
50-W reverse power protection
country-specific power cord
documentation set (CD-ROM)
|Frequency||9 kHz – 40 GHz|
|Phase Noise @ 1 GHz (20 kHz offset)||-146 dBc/Hz|
|Frequency Switching||<= 600 us|
|IQ Modulation BW (Internal/External)||Up to 960 MHz|
|Modulation Types Available||AM, FM, PM, Pulse|
